At present, the developed motor power is from 30KW to 2800KW. The height of the center is from 160 to 710, and the cooling methods include air cooling, water cooling, air-water cooling and etc.
Due to the different tire processing formulas and processes, the power saving rate after the use of a permanent magnet motor is from 7% to 40%. The permanent magnet direct drive permanent magnet motor has a more obvious energy-saving effect and better maintenance-free performance.
AIR-COOLED PERMANENT MAGNET MOTOR
Power range: 37kw–250kw
Rated voltage: 380V, 6KV, 10KV
Application: Twin screw extruder, single compound extruder, closed rubber mixer, open rubber mixer,
Electricity saving range: Replace DC motor: 15–25%
Replace Asynchronous motor: 7–12%
OPEN TYPE AIR-COOLED PERMANENT MAGNET MOTOR
Power range: 110kw–250kw
Rated voltage: 380V
Application: Compound extruder (equipment with particularly small frame size)
Electricity saving range: Replace DC motor: 15–25%
WATER-COOLED PERMANENT MAGNET MOTOR
Power range: 37kw–250kw
Rated voltage: 380V, 6KV, 10KV
Application: Twin screw extruder, compound extruder, closed rubber mixer, open rubber mixer,
Electricity saving range: Replace DC motor: 15–25%
Replace Asynchronous motor: 7–12%
AIR WATER-COOLED PERMANENT MAGNET MOTOR
Power range: 37kw–2500kw
Rated voltage: 380V, 10KV
Application: closed rubber mixer
Electricity saving range: Replace DC motor: 15–25%
Replace Asynchronous motor: 7–12%
